| Applicable model |
| 5010/5020, 6310, 6315 |
* Cannot be used for power measurement.
 |
 |
|
| Conductor size | Φ40 |
| Rated current | AC 70A |
| Output voltage | AC 3500mV/70A (AC 50mV/A) |
| Accuracy | 0~40A |±1.0%rdg±0.1mV (50/60Hz) |±2.0%rdg±0.2mV (40Hz~1kHz) 40~70A |
| Withstand voltage | AC 3540V for 5 seconds |
| Cable length | Approx. 2m |
| Output connector | MINI DIN 6pin |
| Operating temperature ranges | 0~50ºC, less than 85% RH (without condensation) |
| Output impedance | Approx. 100Ω |
| Applicable standards | IEC 61010-1:2001, IEC 61010-2-032:2002, CAT.III 300V pollution degree 2 |
| Dimensions | 128(L) x 81(W) x 36(D) mm |
| Weight | Approx.240g |
| Accessories | 9095 (Portable case), Instruction manual, Cable marker |
| Option | 7146 (Banana Φ4 adjuster plug) 7185 (Extension Cable) |
