| Dust and drip proof construction. (designed to IEC 60529 IP54) | |
| • | Designed to meet IEC 61010-1 and IEC 61557 safety standard. |
| • | 1mA rated test current at the minimum resistance. |
| • | 200mA measuring current on continuity testing. |
| • | Automatic discharge of circuit capacitance. (Any charge stored in the circuit under test will be automatically discharged after testing.) |
| • | Live circuit warning buzzer and neon lamp. |
| • | Small and lightweight. Shock resistant new case material. |
| • | AC voltmeter with linear, easy-to-read scale. |
| • | Operates on AA, R6P×6 dry batteries. |
| Insulation Resistance | |
| Test Voltage | 250V/500V/1000V |
| Measuring Ranges (Mid-scale Value) |
100MΩ/200MΩ/400MΩ (1MΩ) (2MΩ) (4MΩ) |
| Output Voltage on open circuit |
Rated test voltage+20%, -0% |
| Nominal Current | 1mA DC min. |
| Output Short Circuit Current |
1~2mA DC |
| Accuracy | 0.1~10MΩ/0.2~20MΩ/0.4~40MΩ (Accuracy Guaranteed Ranges) ±5% of indicated value |
| Continuity | |
| Measuring Ranges (Mid-scale Value) |
3Ω/500Ω (1.5Ω) / (20Ω) |
| Output Voltage on open circuit |
4.1V DC approx. |
| Measuring Current | 210mA DC min. |
| Accuracy | |±1.5% of scale length |
| AC Voltage | |
| AC Voltage | 0~600V AC |
| Accuracy | |±5% of scale length |
| General | |
| Safety Standard | IEC 61010-1 CAT.III 600V Pollution Degree 2 IEC 61010-2-031 IEC 61557-1/2/4 |
| IP Rating | IEC 60529-IP54 |
| EMC Standard | IEC 61326-1 |
| Withstand Voltage | 3700V AC for 1 minute |
| Power Source | R6P (AA) (1.5V) × 6 |
| Dimensions | 106(L) × 160(W) × 72(D)mm |
| Weight | 560g approx. |
| Accessories | 7122B (Test leads) Pouch for test leads 8923 (F500mA/600V fuse) × 2 R6P (AA) × 6 Shoulder Strap Instruction Manual |
