| Continuity: 20/200Ω 200mA Test Current |
|
| • | Insulation: 500/1000V, 20/200MΩ 1mA Rated Test Current |
| • | Loop Impedance: 20/2000Ω 15mA Test Current at 2000Ω (No RCD Trip) |
| • | RCD: 10/30/100/300/500mA x1/2, x1, Fast Trip(40ms), DC, Auto Ramp |
| • | Test of a large kind of RCD's: Standard, Selective, AC and A (DC sensitive breakers) |
| • | Uc(Contact Voltage): 100V |
| • | Designed to IEC 61010-1, IEC 61557 |
| • | Data Memory:300 measured results |
| • | The stored data can be transferred to PC via Optical Adaptor Model 8212-USB or 8212-RS232C. |
| Continuity Testing | ||
| Measuring Range | 20/200Ω (Auto-Ranging) | |
| Open Circuit Voltage | > 6V | |
| Short Circuit Current | > 200mA | |
| Accuracy | ±(3%rdg + 3dgt) | |
| Insulation Resistance Testing | ||
| Measuring Range | 20/200MΩ (Auto-Ranging) | |
| Test Voltage | 500/1000V | |
| Open Circuit Voltage | +20% - 0% | |
| Rated Current | > 1mA | |
| Accuracy | ± (3%rdg + 3dgt) | |
| Loop Impedance Testing | ||
| Impedance Range | 20/2000Ω | |
| Rated Voltage | 230V + 10% - 15%(50Hz) | |
| Normal Test Current | 20Ω:25A/10ms 2000Ω:15mA/350ms max. |
|
| Accuracy | ±(3%rdg + 8dgt) | |
| RCD Testing | ||
| Test Current (Test Current Duration) |
x1/2, x1 | 10, 30, 100, 300, 500mA (2000ms) |
| Fast | 150mA (50ms) | |
| DC | 10, 30, 100, 300mA (2000ms), 500mA (200ms) | |
| Auto Ramp | Goes up by 10% from 20% to 110% of IΔn. 300ms×10 | |
| Rated Voltage | 230V + 10% - 15% 50Hz | |
| Accuracy | Test Current | x1/2: -8%-2% x1, FAST: +2%+8% DC: ±10% Auto Ramp: ±4% |
| Trip Time | ±(1%rdg + 3dgt) | |
| Uc Testing | ||
| Measuring Range | 100V | |
| Rated Voltage | 230V + 10% - 15% (50Hz) | |
| Test Current | 5mA at IΔn = 10mA 15mA at IΔn = 30/100mA 150mA at IΔn = 300/500mA |
|
| Accuracy | +5%+15%rdg, ±8dgt | |
| General | ||
| Safety Standard | IEC 61010-1 CAT.III 300V Pollution Degree 2 IEC 61557-1, 2, 3, 4, 6, 10, IEC 60529 (IP40) |
|
| Power Source | R6 or LR6 × 8 | |
| Dimensions | 175(L) × 115(W) × 86(D)mm | |
| Weight | 840g approx. | |
| Accessories | 7122B (Test leads) KAMP10* (Test Lead with IEC Connector) Pouch for Test leads Shoulder Strap Shoulder Pad Instruction Manual |
|
| Optionals | 7133B (Distribution board test leads) 8212-RS232C (RS232C adaptor with "KEW Report (Software)") 8212-USB (USB adaptor with "KEW Report (Software)") |
|
| * | KAMP10 (AU): Australian plug KAMP10 (UK): British plug (13A) KAMP10 (EU): European SHUKO plug KAMP10 (SA): South African plug |
