| Least affected by external stray magnetic field. | |
| • | 20mA AC max. in proximity to a 15mm-dia conductor carrying 100A AC |
| • | Frequency Selector Switch to eliminate the effect of harmonics. |
| AC A (50/60Hz) | 400mA/4/100A ±2%rdg±4dgt |
| AC A (WIDE) | 400mA/4/100A |±2%rdg±4dgt [50/60Hz] |±3%rdg±5dgt [40~400Hz] |
| Conductor Size | Ø28mm max. |
| Safety Standard | IEC 61010-1 CAT.III 300V IEC 61010-2-032 |
| Effect of External Stray Magnetic Field Ø15mm 100A |
20mA AC max. |
| Frequency Response | 40~400Hz |
| Withstand Voltage | 3700V AC for 1 minute |
| Power Source | R03 (AAA) (1.5V) × 2 |
| Dimensions | 169(L) × 75(W) × 40(D)mm |
| Weight | 220g approx. |
| Accessories | Carrying Case R03 × 2 Instruction Manual |
| Optional | 8008 (Multi-Tran)* |
* This Multi-Tran can not be used for leakage current measurement
