| Applicable model |
| 5000/5001, 5010/5020, 6310 |
* Cannot be used for power measurement.
 |
 |
| Conductor size | Φ24 |
| Rated current | AC 1000mA |
| Output voltage | AC 100mV/1000mA (AC 100mV/A) |
| Accuracy | |±1.0%rdg±0.1mV (50/60Hz) |±2.0%rdg±0.1mV (40Hz~1kHz) |
| Withstand voltage | AC 3540V (50/60Hz) for 5 seconds |
| Cable length | Approx. 2m |
| Output connector | MINI DIN 6pin |
| Operating temperature ranges | 0~50ºC, less than 85% RH (without condensation) |
| Output impedance | Approx. 180Ω |
| Applicable standards | IEC 61010-1, IEC 61010-2-032, CAT.III 300V pollution degree 2 |
| Dimensions | 100(L) x 60(W) x 26(D) mm |
| Weight | Approx.150g |
| Accessories | 9095 (Portable case), Instruction manual |
| Option | 7146 (Banana Φ4 adjuster plug) 7185 (Extension Cable) |
