Features:
Frequency Range : 0.1Hz ~ 10MHz
Waveforms : Sine, Triangle, Square, Ramp, TTL and CMOS Output
External Voltage Controlled Frequency (VCF) Function
Duty Cycle Control with Signal Inversion Capability
Variable DC Offset Control
Two-Step (-20dBx2) and Variable attenuator
Built-In 6 Digit Counter with INT/EXT Function up to 150MHz/High Resolution
LIN/LOG Sweep Mode
Description:
10MHz Function Generator
Specification:
|
MAIN |
|
| Frequency Range | 0.1Hz ~ 10MHz (8 Range) |
| Amplitude | > 10Vpp (into 50Ω load) |
| Impedance | 50Ω±10% |
| Attenuator | -20dB±1dBx2 |
| DC Offset | <-5V ~ >5V (into 50Ω load) |
| Duty Control | 15% : 85% : 15% ~ 1MHz Continue variable (square wave only) |
| Display | 6 digits LED display |
|
SINE WAVE |
|
| Distortion | 1% typical |
| Flatness | ±0.45dB (±5%) |
|
TRIANGLE WAVE |
|
| Linear | > 98% to 100kHz |
|
SQUARE WAVE |
|
| Symmetry | ±2%, 1Hz ~ 100kHz |
| Rise or Fall Time | < 35nS |
|
CMOS OUTPUT |
|
| Max. Frequency | 2MHz |
| Level | < 4Vpp ~ 14.5Vpp±0.5Vpp adjustable |
| Rise or Fall Time | < 120nS |
|
TTL OUTPUT |
|
| Level |
> 3Vpp |
| Rise or Fall Time | < 20nS |
|
|
| Input Voltage | 0V ~ 10V (100 : 1) |
| Input Impedance | 10kΩ±10% |
|
SWEEP OPERATION |
|
| Sweep/Manual |
Switch selector |
| Sweep/Rate | >100 : 1 ratio max. and adjustable |
| Sweep/Time | 0.5sec. ~ 30sec. adjustable |
| Sweep/Mode | Lin./Log. switch selector |
| Sweep/Out | 0V ~ 10±1V |
|
FREQUENCY COUNTER |
|
| INT./EXT. | Switch selector |
| Range | 0.1Hz ~ 10MHz (5Hz ~ 150MHz EXT.) |
| Accuracy | Time base accuracy±1 count |
| Time Base | ±20ppm(23° C ± 5° C)after 30 minutes warm up |
| Resolution | The maximum resolution is 100nHz for 1Hz and 1Hz for 100MHz |
| Input Impedance | 1MΩ // 150pF |
| POWER SOURCE | AC115V/230V±15%, 50 / 60Hz |
| ? | ? |
|
ACCESSORIES |
|
| ? | Instruction manual x 1 Power cord x 1 GTL-101 x 2 |
| DIMENSIONS & WEIGHT | 251(W) x 91(H) x 291(D)mm, Approx. 2.2 kg |
