Features:
-
Backlit LCD
-
Shock absorbing holster
-
1ms Peak (Max/Min) function
-
High speed bargraph
-
PC interface
 |
 |
 |
Specifications:
AC Voltage
| Range | Resolution |
Accuracy
|
| 400mV~750V | 0.1mV~1V | 0.5%+5 |
DC Voltage
| Range | Resolution | Accuracy |
| 400mV~1000V | 0.1mV~1V | 0.3%+2 |
AC Current
| Range | Resolution |
Accuracy
|
| 400μA~20V | 0.1μA~0.01A | 1%+5 |
DC Current
| Range | Resolution | Accuracy |
| 400μA~20V | 0.1μA~0.01A | 0.8%+2 |
Continuity
|
Range
|
Active Region
|
 |
< 40Ω
|
Capacitance
|
Function
|
Range
|
Resolution |
Accuracy
|
 |
4nF~40mF
|
1pF~10pF
|
1.9%+20 |
Resistance (Ω)
|
Range
|
Resolution
|
Accuracy | |
|
400Ω~40MΩ
|
0.1Ω~ 1Ω
|
0.3%+2
|
|
Frequency (Hz)
|
Range
|
Resolution
|
Accuracy | |
|
4KHz~40MHz
|
1KHz~10KHz
|
0.05%+1
|
|
RPM
|
Range
|
Resolution
|
Accuracy | |
|
40K~400MRPM
|
0.01K~100KRPM
|
0.05%+1
|
|
Temperature
|
Range
|
Resolution
|
Accuracy | |
|
-50~1000°C
|
1°C
|
1%+2°C
|
|
|
-58~1832°F
|
1°F
|
1%+4°F
|
|
Battery: 9V x 1
Dimensions: 209 x 94 x 48mm
Weight: 600g
*The specifications are subjects to change without prior notice.
Standard Accessories:Battery, test lead, holster, temperature converter, instruction manual |
