STY006 -UVC 254NM METER 220~275 NM from USA

Category: Ultra-Violet meters (UV meters)

Product Description

These instruments are designed to measure ultraviolet light in the range from 220 to 275 nanometers (UVC), 380 to 320 nanometers (UVA) and 280 to 400 nanometers (UVAB). The good illumination range of each kind of meter allow users to conduct the most precise quantitative measurements of ultraviolet radiation.



  • Backlit LCD and 4 Digits dual display
  • High and Low measurements
  • Range in a unit mW/cm2 or uW/cm2
  • Socket of tripod mounting
  • Automatic measuring
  • Low battery indicator
  • Magnetic mount
  • 20 points memory



Specifications



STY006-UVC



Spectrum Range



220~275



Calibration Point



254 nm



Illumination Range

1 uW/cm2 ~ 9999 uW/cm2 / 0.01 mW/cm2 ~ 40.00 mW/cm2

Accuracy 23 ?oC(73.5 ?oF)

+-4% digit

Over Range

Indication "-HI-"

Zero Adjust

YES

Auto Record

YES

Sample Time

Approx. 0.3 sec.

Display

Backlit LCD and Dual Display

Memory

20 points and 1 for interval time

Operation Temperature

0~50oC(32~122oF); 10~90% RH

Battery Type

9V (006P, IEC6F22, NEDA1604)

Weight

Approx. 90g

Dimension

140 x 49 x 29 cm (5.51 x 1.93 x 1.14 inch)

Accessory

9V Battery, UV sensor probe, Instruction Manual

Location

Ask about this product
